Product Details:
Payment & Shipping Terms:
|
Brand: | KRIPAL | Current: | 10A |
---|---|---|---|
Power Supply: | 220V; 380V | Color: | Blue / Yellow / Black |
Purpose: | Controlling Water Level | Customized: | Color |
High Light: | Cable Float Level Switch,Water Pump Float Switch |
Liquid Level Controller Cable Float Level Switch for Pump Tank , 220V 380V
Description:
Cable Float Switch is a control device for automatic On/Off pumps, motor and magnetic valves. It is also an alarm device at certain pre-determined surface levels. It is suitable for use in non-flammable liquids at 250 volts. In dangerous environments (e.g. wells and pumping stations) we recommend 24 V voltage. In potentially explosive atmospheres (e.g. oil tanks) the Switch can be used in conjunction with (Ex) I-isolator switch units. Due to its large float casing the float Switch has a buoyancy which guarantees smooth, trouble-free operation under all conditions. The switch has double chamber and a final remolding finish to make it absolutely hermetic.
Specifications:
Float Regulator |
Liquid Controller /float switch |
Rated voltage |
220V(380V) |
Rated Frequency |
50Hz/60Hz |
Rated current |
10A(3A) |
Working temperature |
0 degee to 80 degree |
Mechanical endurance |
≥100.000 times |
Electric endurance |
≥ 50.000 times |
Protection grade |
IP68CS |
Standard cable length |
2m 3m 5m 10m 20m as customs required |
Switch currency |
+++ ≥50 000switch workings tested by VDE specialization |
Protective connection |
T 70U |
Protection |
waterproof |
Working pressure |
max.1bar |
Circuit breaking capacity |
Directly KW with 250V |
Float |
Polypropylene |
Cable |
polypropylene Jacket |
Counter Weight |
Polypropylene Sealed Housing |
Cable Material |
HO7RN- F3x0.75mm2 , PVC (3x0. 5mm2,3x0.75mm2, 3x1.0mm2) |
APPLICATION
Used in sumps,Sewage,factory drainage,sludgy & soil water containing suspensions for automatic switching
of pumps, submerged pumps, solenoid valves, alarms etc.
Competitive Advantage:
1. The core of cable is real copper not copper - covered aluminum
2. Good micro switch in the ball ensure the long life of float switch
3. The raw materials of plastic are brand-new with high quality
Why Choose Us?
1. We always consider the benefit of the clients first, because we pay special attention to the reputation of
our company.
2. We have extensive experience in this field because we have dealing the line for more than 21 years.
3. The prices of our products are very reasonable because we have very good network for supply of raw
material, spare parts and goods. The area of our factory is 25,000 square meters.
4. The quality of our products are very reliable because we have a group of professional inspectors to control
the quality during the production and before shipment. Our products have obtained TUV, SAA, KEMA, UL, SEMKO, CE, CB, ROHS certificate.
5. The packing of our products are very attractive because we have special designers to arrange good packing
material in unique style.
6. The service from our company are very good because we have experience salesmen to handle business
for you specially
