Telemecanique Motor AC Magnetic Contactor 3 Phase IEC60947-4-1

Telemecanique  Motor AC Magnetic Contactor 3 Phase IEC60947-4-1
Telemecanique  Motor AC Magnetic Contactor 3 Phase IEC60947-4-1

Large Image :  Telemecanique Motor AC Magnetic Contactor 3 Phase IEC60947-4-1

Product Details:
Place of Origin: Zhejiang,China(Mainland)
Brand Name: JIELI
Certification: CE/ISO9001/IEC60898-1
Model Number: JL-GMC-65
Payment & Shipping Terms:
Minimum Order Quantity: 500pieces
Price: Negotiable
Packaging Details: Standard export carton or according to your request.
Delivery Time: Within 20 days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,CASH
Supply Ability: 100000pieces per month.
Detailed Product Description
High Light:

telemecanique magnetic contactor

,

Electric Motor Contactor



New and old types of ac magnetic contactor of JL-GMC-65



Quick Detail:



Place of Origin:

Zhejiang China (Mainland)

Brand Name:

JIELI

Model Number:

JL-GMC-65

Electricity Type:

AC magnetic contactor

Number of Pole:

3

Phase:

 3

Main Circuit Rating Voltage:

200-240V, 380-440V, 500-550V, 690V

Main Circuit Rating Current:

up to 135A

Standard:

IEC60947-4-1

Rated working current:

up to 135A

Rated working voltage:

up to 660V

Type:

New / Old type



Description:







JL-GMC-65 series AC magnetic contactor is suitable for frequency 50Hz/60Hz, rated voltage up to 660VAC and rated current up to 135A.

JL-GMC-65 series AC magnetic contactor is used for making/breaking electric circuit at a long distance & for frequent starting/stopping & controlling AC motors.

JL-GMC-65 series AC magnetic contactor is used in combination with thermal relay to compose a magnetic motor starter.

JL-GMC-65 series AC magnetic contactor complies with IEC60947-4-1 standard.



Specifications:







Type

GMC-9

GMC-12

GMC-18

GMC-22

GMC-32

IEC-60947

AC 1 duty

20A

20A

25A

32A

50A

AC3 duty

200-240V

2.5KW11A

3.5KW13A

4.5KW18A

5.5KW22A

7.5KW32A

380-440V

4KW9A

5.5KW12A

7.5KW18A

11KW22A

15KW32A

500-550V

4KW7A

7.5KW12A

7.5KW13A

15KW22A

18.5KW28A

690V

4KW5A

7.5KW9A

9.5KW9A

15KW18A

18.5KW21A

UL

Continuous current (Ith)

20A

25A

30A

32A

45A

AC motor

Single phase

115V

0.5HP

0.5HP

1HP

2HP

2HP

230V

1HP

2HP

3HP

3HP

5HP

Three phase

200V

2HP

3HP

5HP

7HP

7.5HP

230V

3HP

3HP

5HP

7.5HP

10HP

460V

2HP

7.5HP

10HP

10HP

20HP

575V

5HP

10HP

15HP

15HP

20HP

Life time (unit:10,000 time)

Electrical

250

250

250

250

200

Mechanical

2500

2500

2500

2500

1500

Aux.contact

1NO1NC

1NO1NC

1NO1NC

1NO1NC

1NO1NC

2NO2N



Type

GMC-40

GMC-50

GMC-65

GMC-75

GMC-85

IEC-60947

AC 1 duty

60A

80A

100A

110A

135A

AC3 duty

200-240V

11KW40A

15KW55A

18.5KW65A

22KW75A

25KW85A

380-440V

18.5KW40A

22KW50A

30KW65A

37KW75A

45KW85A

500-550V

22KW32A

30KW43A

37KW60A

45KW64A

45KW75A

690V

22KW25A

30KW33A

37KW33A

45KW47A

45KW52A

UL

Continuous current (Ith)

50A

70A

80A

90A

100A

AC motor

Single phase

115V

3HP

3HP

5HP

5HP

7.5HP

230V

5HP

7.5HP

10HP

15HP

15HP

Three phase

200V

10HP

10HP

15HP

20HP

25HP

230V

10HP

15HP

20HP

25HP

30HP

460V

25HP

30HP

40HP

50HP

50HP

575V

25HP

30HP

40HP

50HP

50HP

Life time (unit:10,000 time)

Electrical

200

200

200

200

200

Mechanical

1500

1000

1000

1000

1000

Aux.contact

standard

2NO2NC

2NO2NC

2NO2NC

2NO2NC

2NO2NC



About our company-JIELI:







1. JIELI Electrical is abbreviation for" Alliance of JIELI Electrical Industry", with JIELI brand and ICEDC brand.

2. JIELI Electrical have 29 members and more than 2000 employers, all of the plants area are about 50000 square meters.

3. JIELI Electrical devoted in producing low-voltage circuit breaker and other related products. .

4. At present, JIELI main products MCB,MCCB,RCCB, Distribution box, AC contactor, Relay, Switch and more than thousands electrical goods spare parts.
