OEM / ODM Signal / Power M12 6pin Connector Waterproof

Large Image : OEM / ODM Signal / Power M12 6pin Connector Waterproof

Product Details:

Place of Origin:	Zhejiang,China(Mainland)
Brand Name:	JIELI
Certification:	CE/ISO9001/CB/TUV
Model Number:	JL-PG

Payment & Shipping Terms:

Minimum Order Quantity:	2000 Piece/Pieces other
Price:	Negotiable
Packaging Details:	carton package
Delivery Time:	Within 20 days
Payment Terms:	L/C,D/P,T/T, Western Union, MoneyGram
Supply Ability:	50000POLES/DAY

Contact Now

Detailed Product Description

Model Number:	JL-PG	Waterproof Rate:	IP68
Current Rating:	5-7A	Number Of Contacts:	2,3,4,5,6,7,8
Cable:	Customized	Insulation Resistance:	≥500 MΩ At DC500V
Contact Resistance:	<5mΩ	Protection Ration:	IP67, 300mm Water Half An Hour / IP68 10m Water 2 Weeks
Highlight:	single pole circuit breakers

OEM / ODM Signal / Power M12 6pin Connector Waterproof

Specification:

Description	Details	Code
1. Connector Size	PG	PG
2. Current Rating	5-7A	5-7
3. Number of Contacts	2,3,4,5,6,7,8	2,3,4,5,6,7,8
4. Connector Type	Without SR/SR	S
5. Connector Gender	Male,Female	M,F
6. Contact Gender	Male,Female	M,F
7. Assembly Style	Field Installation /Molding(Solder)	M/A
8. Mating Style	Screw	S
9. Backs hell	Straight/Right angle/T	ST/RA/T
10. Waterproof Rating	IP67IP68	7/8

Material:

Core Material: PA6+30%GF UL94V0

Mold Material: Waterproof PVC

Pin and Hole: Brass, Nickle Plated or Gold plated

Sealing: Silicone

Cable: Customized

Other type cable for customize

Property :

Contact Resistance: <5mΩ

Insulation Resistance: ≥500 MΩ at DC500V

Breakdown Voltage: ≥2.5kV normal, 1.0kV water

Temperature Rating: -45℃~+105℃

Protection Ration: IP67, 300mm water half an hour / IP68 10m Water 2 weeks

Durability: 3K plug/Unplug Cycles

Applications:

·New energy

·LED

·Industrial control product

·Automotive

·Security product

·Power Supply

·Electric Vehicle

·Solar Energy

·IPC

·Various Mold

It is high performance and competitive price.

Welcome OEM/ODM.
