660V high voltage AC Magnetic Contactor , vacuum AC contactors for motor With thermal relays 8kw

Large Image : 660V high voltage AC Magnetic Contactor , vacuum AC contactors for motor With thermal relays 8kw

Product Details:

Place of Origin:	China
Brand Name:	Wu Yin
Certification:	ISO
Model Number:	A-D

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	According to customer’s requirment
Delivery Time:	7-15days
Payment Terms:	L/C,T/T,Paypal
Supply Ability:	50000/MONTH

Contact Now

Detailed Product Description

Rating Voltage:	660V	Electricity Type:	AC
Feature:	High Voltage	Product Name:	AC Magnetic Contactor
Type:	Vacuum	Usage:	Motor
Highlight:	magnetic contactor switch

660V high voltage AC Magnetic Contactor , vacuum AC contactors for motor With thermal relays 8kw

Application

SHF series AC contactors are mainly used in 50/60Hz electrical lines of the rated voltage up to 660V AC and rated current up to 475A, are applicable for remote making and breaking of electrical lines or frequent control of AC motors. Usually,
it can be combined with the thermal relay to form electromagnetic starters which have overload and open-phase protection. It complies with IEC60947-4.

Speciﬁcarions

Contactor Model		A9D	A12D	A16D	A26D	A30D	A40D	A50D
Standard		IEC60947-1/IEC60947-4-1
Product Qualification		CE
Rated insulation voltage(V)		690
Rated frequency range(Hz)		25-400
Conventional thermal current Ithθ≤40℃(A)		22	25	27	30	45	60	100
Apply Altitude (m)		＜3000
Ambient temperature (℃)		Alone Use: -40~+70
		With the use of thermal relay: -25~+55
Rated operating current IeAC-3, (380-400V)(A)		9	12	16	22	30*	37	50
Electric motor power (KW)	220-240V	2.2	3	4	6.5	9**	11	15
	380-400V	4	5.5	7.5	11	15***	18.5	20
Electrical operating frequency limit(AC-3)(Times / hour)		1200						600
Mechanical life (operating cycles)		10
Limit mechanical operation frequency (times / hour)		3600
Pick-up voltage range		0.85-1.1Uc
Coil Power 50/60Hz	Pick-up meanVA	74/70				125/120		190/180
	Maintain the meanVA/W	8/2				12/3		18/5.5
Auxiliary contact	Before Loading	CA5-10/CA5-01
	Side loading	CAL5-11
Conventional thermal current of auxiliary contact Ithθ≤40℃(A)		16
Rated insulation voltage of auxiliary contactsUi (V)		690
Rated operating current of auxiliary contacts Ie(A)	AC-15(24/220/380)	6/4/3
	DC-13(24/125/250)	6/0.55/0.3
Dimensions (B×H×P)		44×74×74				54×90×93.6	54×90×108.3	70×110×108

Note:

* With thermal overload relays 28A;

** With thermal overload relays 8kw;

*** With thermal overload relays 14kw

660V high voltage AC Magnetic Contactor , vacuum AC contactors for motor With thermal relays 8kw 0

A63D	A75D	A95D	A110D	A145D	A185D	A205D	A260D	A300D	A370D
IEC60947-1/IEC60947-4-1
CE
1000
25-400
115	125	145	150	160	250	275	350	400	500
＜3000
Alone Use: -40~+70
With the use of thermal relay: -25~+55
65	75	95	110	145	185	205	260	300	370
18.5	22	25	30	45	55	59	80	90	110
30	37	45	55	75	90	110	140	160	200
60		300
10					5
3600
0.85-1.1Uc
190/180		410/365			700/650		125/120
18/5.5		27/7.5			44/13		12/3
CA5-10/CA5-01					No before Loading
CAL5-11		CAL18-11
16
6/4/3
6/0.55/0.3
70×110×108		90×148×123.5			105×196×160		140×227×180.5
