Colorful PCB Membrane Keyboard Switch 3M Adhesive With 0.05mm - 1.0mm Control

China Colorful PCB Membrane Keyboard Switch 3M Adhesive With 0.05mm  - 1.0mm Control supplier
Colorful PCB Membrane Keyboard Switch 3M Adhesive With 0.05mm  - 1.0mm Control supplier Colorful PCB Membrane Keyboard Switch 3M Adhesive With 0.05mm  - 1.0mm Control supplier

Large Image :  Colorful PCB Membrane Keyboard Switch 3M Adhesive With 0.05mm - 1.0mm Control

Product Details:

Place of Origin: China
Brand Name: TKM MS
Certification: ISO9001:2008, SGS,Rohs
Model Number: TKM--MS--398

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Price: negotiation
Packaging Details: Polybag per pcs,50per cartoon
Delivery Time: 15-20days
Payment Terms: T/T , Western Union, L/C
Supply Ability: 100000Pieces per month
Contact Now
Detailed Product Description
Material: PC Circuit: PCB
Connector: Nicomatic Rear Adhesive: 3M468

Colorful PCB Membrane Keyboard Switch 3M Adhesive With 0.05mm  - 1.0mm Control









Quick Detail:



Type

PCB

Feature

Electronic Products

Machine Stiffness

Rigid

Lays



1-26

Material

PET /PC

I nsulation Material

Organic resin

I nsulation layer thichness

General

Antiflaming Speciality

VO

Processing Technic

Electrolytic foil

Reinforcing material

Glass fiber

Insulating Resin

Phenolic

Export Markets

Global





Description:



1. Copper foil substrate (Copper Film)
Copper foil: basically divided into two kinds of electrolytic copper and rolled copper common thickness 1oz 1/2oz and 1/3 oz
Substrate film: a common thickness of the 1mil with 1/2mil two kinds.
Glue (adhesive): thickness according to customer requirements.



2. Cover film protection film (Cover Film)
Cover film protection film: surface insulation. The common thickness 1mil with 1/2mil.
Glue (adhesive): thickness according to customer requirements.
Adhesive buildup of foreign matter before pressing the shape from the paper: avoid; easy job.



3. Stiffener (PI Stiffener Film)
Stiffener: reinforcing the mechanical strength of the FPC, to facilitate the surface mounting job. Common thickness 3mil to 9mil.
Shape from the paper: to avoid foreign matter adhesive buildup Crimping before the.



4. EMI: electromagnetic shielding film, the protection circuit board line without interference from the outside world (a strong electromagnetic District or susceptible to interference zone).




Applications:


1. Disk drives
Regardless of the hard disk, or diskette, is very dependent on FPC high softness and thickness of the 0.1 mm slim, read data finish quickly. Either a PC or NOTEBOOK.


2. Computer and LCD screen
Use the one line configuration of flexible circuit boards, and thin thickness. The digital signal into the picture, through the LCD screen


3. CD player
Focuses on three dimensional assembly characteristics of flexible circuit boards and thin thickness. The huge CD to carry around


4. The mobile phone
Focuses on the flexible circuit board light weight and thin thickness. Can effectively save the volume of products, easy connection of the battery, microphone, and buttons and into one.









Specifications



As per request OEM/OEM



Wire lead resistance:<1Ω/CM

Life time:>1 Million times

Rated current:25-100mA,0~30V DC

Operation Temperature:-40℃~70℃

Rated Voltage:<50V, DC

Operation Humidity:at40℃,<98%RH

Insulation resistance:<100MΩ,250V DC

Dome springback time:<5 msec

Switch travel:Flat Type 0.05-0.3mm   tactile type:0.3-1.5mm

Base Material voltage withstand:1500 V DC

Tail flexiblility:any angle within 180 degree







Competitive Advantage:

  • High reliable in function
  • Long life over 1 million operation times
  • Function test 100% before shipment
  • Long history in the industry
  • Experiences in cooperation famous brands such as SANYO, Philips etc.
  • Three factories to support mass production
  • Low cost
  • Professional staffs and in administration level
  • Expert sales team to support customer services.
  • Perfect exterior & rising available
