Auto resetting circuit breaker 5A 10A 15A For Battery Protector and DC audio systems

Large Image : Auto resetting circuit breaker 5A 10A 15A For Battery Protector and DC audio systems

Product Details:

Place of Origin:	CHINA
Brand Name:	VICTOR
Certification:	SGS UL
Model Number:	E511

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	Negotiation
Packaging Details:	standard export packing for Resettable Circuit Breaker
Delivery Time:	10~15 working days after received your payment
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	30000 PCS for 20 works day.

Contact Now

Detailed Product Description

Product Name:	Resettable Circuit Breaker	Protection Class:	IP67
Rated Operating Temperature:	25°F(32°C)to180°F(82°C)	Rated Storage Temperature:	30°F(34°C)to300°F(149°)
Terminal:	10-32 Thread And Quick-connector Available	Torque Rating:	24in-lb(2.7Nm) Max
Standard:	SAEJ1625;ABYCE-11;CE;SAE;J1171	Rating:	5-50A, 14VDC, 28VDC(For T2 And T3)
Interrupt Rating:	2.5KA @ 12VDC(T1& T1-28VDC, SEALED & T3)
Highlight:	overcurrent protection circuit breaker

Self-resetting Characteristics Resettable Circuit Breaker For Battery Protector

Feature

Single pole thermal trip

Mouting

Stud mount,2*10/32stud.0.66(Aux)0.50(Batt)

Rating

5,10,15,20,25,30,40,50A

Voltage

14Vdc,(24Vdc need special noted)

IP grade

Plase cover has splash /dust proof

Safety

Meets SAE J553 specification

Applications: Typically used in auxiliary and accessory circits in truck, bus', RVs and marine systems.

Others include battery chargers and DC audio systems.

Materials: Black UL rate thermoplastic body, (thermo set for T2 body & button)

Cover is gray thermoplastic or steel, T1-gold, T2-Silver

Packing Information:
Carton packing
Gross weight: 11KG
Carton size: 30*29*23cm
