School Bus HDD Mobile DVR Big Storage Alarm Recording Double Channel
Quick Detail:
|
Feature:
|
3G+Wifi+G-Sensor
+GPS ( Recording)
|
Application
|
Bus,
Business Car,
Official Car,
Regular Vehicle
|
|
Video Compression
|
H.264 Format
with HiSilicon
High Speed Processor
|
Unique UPS
|
work for
10-15sec
when power
failure occurs
|
|
Card Storage
|
Support 32G,
64GB Max
|
Extra Function
|
Support
3G remote
fule cut-off
and power-off
|
|
Industrial design
|
Aluminium
materials
|
Certificate
|
CE,
RoHS,
FCC
|
Description:
• Recording resolution: CIF/ 2CIF/ D1 optional, maximum support 2CH of D1 & 2CH of CIF;
• Support 2 SD Cards, 32GB for each);
• Support GPS, G-Sensor, Gyro-Sensor module;
• Support 3G remote fule cut-off and power-off and local and remote PTZ control;
• Unique UPS technology ensures the integrality of record when power failure occurs,
even can work for 10-15sec
• Support GPS, 3G and Wifi Module Optional, WCDMA/CDMA2000/TD-SCDMA optional,
• support Wifi and 3G Auto Downloading, resume from breakpoint ( 4G can be updated);
• Industrial design; Aluminium materials, heat-proof ,damp -proof & dustproof
• With complete client Software Platform, support Real time Video view, Record, Snap,
Replay analysis
Applications:
1. City Transportation
Prevention for Speeding, overloading, accident disputes, passengers disputes and so on
2. Taxi Transportation
Crime presentation, Driver protection, As an evidence of segregation responsibility when the
event of passengers disputes occur
3. Long Distance Coach Transportation
Prevention for Speeding, Overloading, Halfway Passengers get on/off Charges, Accident
and passengers disputes
4. Logistics vehicles Transportation
For damaged goods in transit occurs, loss and other problems, unable to distinguish events
prove liability, logistics companies and customers and insurance companies often dispute
the goods for compensation
Specifications:
|
Item
|
Description
|
|
Model
|
ASM3GG90W
|
|
Operating System
|
Linux (2.6)
|
|
Connection
|
3G+G-sensor+GPS
|
|
Video Compression
|
H.264 main profile
|
|
OSD
|
Overlays letters and log
like some date & time info
and vehicle ID into
video streaming.
|
|
GUI
|
Graphical User Interface
|
Setup system
parameters through
the remote control.
|
|
Video and Recording
System
|
Video input
|
1-4 channels input,
4 CVBS, 1.0Vp-p, 75Ω
|
|
Video output
|
1CH output, CVBS,
1.0Vp-p, 75Ω,
single or quad monitor
|
|
Preview
|
Support 1 channel and
4 channels preview. Also
can preview through PC,
with PC Viewer software.
|
|
Recording Resolution
|
Support CIF, HD1,
D1 resolution optional,
maximum 2CH of
D1 & 2CH of CIF.
|
|
Video Quality
|
1-4 levels,
1 is the highest level ,
4 is the lowest level.
|
|
Recording
|
PAL: 100Frame/s ,
CCIR625 line,50 field
NTSC: 120Frame/s,
CCIR525 line,60 field
CIF: 256Kbps ~ 1.5Mbps,
4 quality level support,
HD1: 600Kbps ~ 2.5Mbps,
4 quality level support
D1: 800Kbps ~ 3Mbps,
4 quality level support
|
|
Video stream
|
ISO14496-10 standard
|
|
Recording Mode
|
Default auto recording
after power on,
support timed recording,
alarm recording
|
|
Audio
|
Audio Input
|
Mic or line in,
up to 2
channels
|
|
Audio Output
|
1 channel output,
output voltage:
1V ~2V
|
|
Compression
|
G.726, 5KB/s
|
|
Playback
System
|
Video Search
|
Search video via time,
type(normal or alarm),
target SD card
|
|
Playback
|
Support 1 to 4
channels playback.
|
|
Support forward and back
at the speed of: x 2,x4,x8,x16.
|
|
Alarm
|
Input
|
Support up to 4
channels alarm
input.
|
|
Alarm recording: include the
recording within
15 seconds ahead
of the alarm starting, and
the recording after alarm
dynamically adjusted ..
|
|
Output
|
2Ch alarm
output,
level signal.
|
|
Communication Port
|
RS232 for
remote control;
RJ45
|
|
Storage
|
SD Card
|
Support 2 SD Cards,
32GB for each.
Support SD card
recycle recording.
Automatically switch
to the other SD
Card after the
one is full,
and the data will be
automatically overwritten .
|
|
Firmware upgrade
|
Upgrade with
SD card
|
|
File Format
|
ASF
|
|
File System
|
FAT32
|
|
Power
|
Power Management
|
System auto power on/off mode:
1, Vehicle acc on/off---
system auto power on after acc on,
system power off
according to the delay time
(up to 240min, default 5min)
after acc off.
2, Preset time---
Only according to
time preset table.
|
|
Power Supply
|
DC:+8V ~ +36V
|
|
Power Output
|
+12V@1.5A；+5V@1.5A
|
|
Power-off data protection
|
All data can be saved
and the recording
files can
be closed normally
in case of power lost.
|
|
Working Environment
|
Temperature
|
-20℃ to + 70℃
|
|
Humidity
|
20% to 80%
|
|
Others
|
Dimensions
|
112(W) x36
(H) x138(D) mm
|
|
Net Weight
|
0.65g
|
Why to choose Auras Sam This style Mobile DVR?
1. This Mobile DVR is designed for mass-market mobile monitoring design a cost-effective
vehicle monitoring SD recorder.
2. Wide power input, SD card, USB, use a professional and reliable air plug connector;
support the expansion WIFI, GPS, 3G module.
3. Appearance of small simple operation and easy installation, the system is stable.
Support mobile phone monitoring.
4. Widely used in passenger cars, buses, taxis, school buses, logistics vehicles,
dangerous goods vehicles, private cars, and ships.
Communication with customers
A: Hello, Can you help me ? What’s the different from ASMG90 and ASM3GG90?
B: Dear, We are Auras Sam Technology LTD in china. Pleasure to help you.
ASMG90 just the basic version with G-sensor Function for recording,
But ASM3GG90 can use the 3G SIM card for the data transmission and Real-time monitoring,
plus the GPS can locate the vehicles precisely that can be understood easily to the work fields
by you. The G-Sensor Function can protect the data in the DVR ahead. Meanwhile, the series
support Two SD Card and 32G SD card each storage at the same time (high-capacity SD card) .
A: well ,we never had a problem with them before but we bought some from other suppliers,
how that for quality control in your factory?
B: we have the FCC, QC and CE to inspection the Mobile DVRs and the defective rate is 0.3%.
A: How long time for 500pcs ASM601?
B: 4-12 Days is okay with laser Logo and Silk-print.
A: Which shipping partner is available to UK?
B: DHL, UPS, TNT, FEDEX, EMS and shipment by air or sea are okay. Which shipping cost is
cheaper and speed is good, i will suggestion to you. 3-4 days can arrive UK.
A: How long is your quality guarantee period
B: In usually, the DVR is 24 month.
A: Great, TKS. Do it.
