The mini circuit breaker (MCB)10kA

Large Image : The mini circuit breaker (MCB)10kA

Product Details:

Place of Origin:	China
Brand Name:	KRIPAL
Certification:	CE
Model Number:	UKB7

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pcs
Packaging Details:	Packed in standard exporting cartons
Delivery Time:	20 days
Payment Terms:	T/T, L/C, D/P
Supply Ability:	200,000 pcs per month

Contact Now

Detailed Product Description

The mini circuit breaker (MCB)10kA

Number of Poles: 1P, 2P, 3P, 4P
Rated current(A): 1, 2, 3, 4, 6, 10, 16, 20, 25, 32, 40, 50, 63
Voltage(V): 230/400
Rated breaking capacity (KA): 10

Main feature

1. Conforming of latest standard
2. Accurate current tripping and setting
3. High breaking capability up to 10kA
4. High current limitation capability to realize the high selection
5. Dual-thermal at the sides is suitable for the bus bar and single-core conductor
6. Wiring screw of combined channel with large torque and solid wiring and rapid wiring
7. Free incoming-line direction of power supply
8. DC product could be used at the fields such as communication or electric vehicle and so on.

Technology Specification & Electrical Specification
Electric standard	IEC60898; GB 10963
Rated voltage	230V; 50HZ 230V/400V
Rated surplus operating current	10; 30; 100; 300mA
Selection grade	3
Rated braking capacity	10kA IEC898
Rated current	0.5-63A
Tripping character	B, C, D characteristic curve
Maximum connected fuse	100A gL(> 10kA)
Work environment temperature	-5 to +40 degree
Case protection grade	IP40 after installation
Electric life	Not less than 8000 times of breaking and closing
Mechanical life	Not less than 2000 times of breaking and closing
Mechanical Parameter
Installation mode	Installation at the DIN guide rail of 35mm
Terminal block capacity	Conductor1-25mm; Generatrix thickness 0.8-2mm
The length of exposed plane	45mm
Enclosure height	80mm
Enclosure width	17.5mm every pole
Accessories
Auxiliary contact	UKZ7-AHK
Contact with alarm indication	UKZ7-NHK
Shunt trip	UKZ7-ASA
Under voltage trip	UKZ7-USD
