Home Double Pole Professional NC Mini Circuit Breaker 6000A 10000A

Home Double Pole Professional NC Mini Circuit Breaker 6000A 10000A
Home Double Pole Professional NC Mini Circuit Breaker 6000A 10000A

Large Image :  Home Double Pole Professional NC Mini Circuit Breaker 6000A 10000A

Product Details:
Place of Origin: Zhejiang,China(Mainland)
Brand Name: JIELI
Certification: CE/ISO9001/IEC60898-1
Model Number: MN09
Payment & Shipping Terms:
Minimum Order Quantity: 1200 Piece/Pieces other
Price: Negotiable
Packaging Details: Standard Export Carton or according to the your requirements
Delivery Time: Within 20days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,CASH
Supply Ability: 50000POLES/DAY
Detailed Product Description
Highlight:

small circuit breaker


Double Pole Professional NC Mini Circuit Breaker 6000A 10000A



Quick Detail:



Place of Origin:

Zhejiang China (Mainland)

Brand Name:

JIELI

Model number:



MN09

Type:

Mini circuit breaker

Poles Number:

1P,2P,3P,4P,

1P+N,

3P+N

Color:

White

Electrical life

10000

Service short-circuit breaking capacity:

3000A-10000A

Rated impulse with stand voltage:

6000V

Electro-mechanical endurance:

In≤100=10000 In125=8000

Material:

PA66, copper, iron etc.

Mechanical life

4000

POLE:

1P, 2P, 3P, 4P, 1P+N, 3P+N

Voltage:

AC 230(240)/

400(415)V

Product name:

MN09 Mini Circuit Breaker




Description:





1. MN09 mini circuit breaker, as a representative of "harmony" series product,JIELI owned completely independent intellectual property right.
2. MN09 Series mini circuit breaker is designed according to the market research, which means the miniature circuit breaker has a ready market.
3. MN09, this type of mini circuit breaker, has two kinds of function, overload and short circuit protection. The rated capacity of shortcircuit (ICU) of MN09 mini circuit breaker is up to 6000.
4. MN09 mini circuit breaker, this kind of product is in superior quality and the price is competitive. The most important is that JIELI electrical company is in good faith to ensure safety.




Applications:









MN09 mini circuit breaker have protective functions as shortage and overloading, and are used in lighting distribution system in industry, commerce and dwelling, and protect fractional electric motors.






Specifications:






Item name :

MN09

Standard  :

IEC60898/GB10963

Product Certifications   :

CE,CB,3C

Product Function  :

Short circuit protection, Over current protection

Rated current(A)   :

1A-5A, 6A-63A, 80A-125A

No of pole   :

1P,2P,3P

Rated voltage(V)  :

230/400V

Rated frequency(Hz)  :

50/60

Fiducial temperature    :

30°C

Environment temperature  :

-35~70°C

Installation style standard    :

35mm guide

Connection type   :

Tunnel style, Pin style, U style

Biggest wiring ability   :

25mm2

Magnetic tripping curve  :

B(3-5In),C(5-10In),D(10-20In)

(ICU)Rated capacity of short circuit:

6000

(ICS)Operation capacity of short circuit :

6000

Mechanical life :

10000

Electrical life :

4000

Protection degree :

IP20




Competitive Advantage:





1. Non-slip handle design, more comfortable, more effort.
2. Air gap design, improve the heat dissipation capacity.
3. Installation and removal without tools secure and more reliable, saving costs.
4. Busbar design, much easier installation than cable connection.
5. Colorful plating iron, prevent rust.
6. Iron up arc and down arc accelerate the movement speed of the arc, improving arcing effect, help to improve breaking capabilities.



About our company-JIELI:





JIELI Electrical is abbreviation for"Alliance of JIELI Electrical Industry",with JIELI brand and

ICEDC brand.

JIELI Electrical have 29 members and more than 2000employers,all of the plants area are

about 50000square meters.

JIELI Electrical devoted in producing low-voltage circuit breaker and other related products,

At present,JIELI main products MCB,MCCB,RCCB,Distribution box,AC contactor, Relay,Switch

and more than thousands electrical goods spare parts.
