40A 50A 63A 230V Mini Circuit Breaker Single Pole Protection IP20 UL CB


Quick Detail:

Place of Origin: Zhejiang china(mainland)
Brand Name: JIELI
Size: Mini circuit breaker
Protect Feature: Sealed
Usage: General Purpose
Contact Load: High Power
Certificates Obtained: UL, TUV, CQC
Number of poles(p):1p,2p,3p,4p
Rater current(A):6,10,16,20,25,32,40,50,63.
Rated voltage:220-415V
Breakering capacity(A):3000-6000


 Description:

JL-MW type mini circuit breaker have protective functions  as shortage  and overloading.
Mini Circuit Breaker(MCB) is applicable to circuit with rated voltage up 400V AC,  rated frequency 50/60Hz and rated  current  up  to 63A for protection and  control of circuit  against  overload and short circuit in commercial, household and electric equipment installation.
Mini Circuit Breaker is suitable for  non-frequently making and breaking operation.
And JL-MW Mini circuit breaker also have many merits of high protective grade (up to IP20), high breaking capacity, good reliability of sensitive action, convenient multi -pole assorting, long using life etc.


Applications:


JL-MW Mini circuit breaker are used in lighting distribution system in industry,  commerce  and dwelling, and  protect fractional electric motors.
