Nylon Cable Glands Connector of RJ45,M12 ,M16,M22,F/M Panel Solder Type

صورة كبيرة : Nylon Cable Glands Connector of RJ45,M12 ,M16,M22,F/M Panel Solder Type

تفاصيل المنتج:

Place of Origin:	Zhejiang,China(Mainland)
اسم العلامة التجارية:	JIELI
إصدار الشهادات:	CE/ISO9001/CB/TUV
Model Number:	JL-PG

شروط الدفع والشحن:

Minimum Order Quantity:	1200 Piece/Pieces other
الأسعار:	negotiable
Packaging Details:	With blister package, carton size:44.536.523.5(mm) OEM package available
Delivery Time:	Within 20 days
Payment Terms:	L/C,D/P,T/T, Western Union, MoneyGram
Supply Ability:	50000POLES/DAY

اتصل

مفصلة وصف المنتج

Type:	adapter	Operation temperature:	-25°C~+90°
Nominal voltage:	30V AC/DC .
إبراز:	single pole circuit breakers,Isolator Switch

Nylon Cable Glands Connector of RJ45,M12 ,M16,M22,F/M Panel Solder Type

Specification:

field Installable waterproof M12 cable connector
1	Model No.	Instant M-12
2	Material	Connector Body	Nylon(PA66)+GF UL94V-0 1/16''
3		Contact	Brass with Gold Plated
4		Sealing	Silica Gel
5	Property	Current Rating	2x15A
6		Voltage Rating	500V
7		Contact Resistance	<10mΩ
8		Insulation Resistance	1000MΩ at DC 500V
9		Breakdown Voltage	1.5KV/1minute
10		Temperature Rating	-25°C~+105°C
11		Durability(Plug/Unplug)	3000 times
12		Waterproof Rating	IP68
13		Cable Max. Diameter	8mm
14		Contact Range	2, 3, 4, 5, 6, 7, 8, 9, 10, 3+4, 2+5
15	Certificate	CCC; CE; ROSH

Standard of waterproof connector:

The waterproof connector we produced according to standard IEC61076-2-101,this International Standard describes cable connectors M12 typically used for industrial process measurement and control. These connectors consist of fixed and free connectors either rewireable or non-rewireable, with screw-locking
