Product Details:
Payment & Shipping Terms:
|
| Type: | Panel Connector | Protection Level: | IP68 IP67 |
|---|---|---|---|
| Model: | JL-PG | Application: | Power/Signal |
| Cable Max. OD: | 10mm | Mating Style: | Quick Lock |
| Connector Gender: | Male | Contact Gender: | Female |
| Assembly Style: | Panel(by Soldering) |
Plastic PVC 15Pins IP68 IP67 Waterproof Cable Joint For Power / Signal
Specifications:
15Pins Panel Mode Waterproof Connector Parameters | |||
1 | Model No. | LLT-M22 (Panel Rear Mounted) | |
2 | Material | Connector Body | Nylon(PA66)+GF UL94V-0 1/16'' |
3 | Contact | Brass with Gold Plated | |
4 | Sealing | Silica Gel | |
5 | Property | Current Rating | 15x5A |
6 | Voltage Rating | 300V | |
7 | Contact Resistance | <10mΩ | |
8 | Insulation Resistance | 1000MΩ at DC 500V | |
9 | Breakdown Voltage | 800V/1minute | |
10 | Temperature Rating | -25°C~+105°C | |
11 | Durability(Plug/Unplug) | 3000 times | |
12 | Waterproof Rating | IP68 | |
13 | Cable Max. Diameter | 10.0mm | |
14 | Panel Cut-out | 20.5mm-21.6mm | |
15 | Pins Range | 2,3,4,5,6,7,8,9,10,12,15,18,24,3+8,3+9 | |
16 | Certificate | CCC; CE; ROSH | |
Applications:
Primary electrical insulation for all solid dielectric (rubber and plastic) insulated wire and cable splices rated to 1000volts
Meets ANSI C119.1, directly buriable or submersible
For indoor, outdoor, or overhead use
Physical protection and moisture sealing for high-voltage, air-insulated connectors and lugs such as spacer cable and lug connections to bus bar
Insulation of secondary splices copper or aluminium conductors
Relocation of service
Dig-in repairs, sheath repairs
Insulation of inline conductor transition connectors
Sealing of coax cables with Type N or 7/16 DIN connectors on wireless communication towers
